Wiraphan Sheets and Plates, a well-respected manufacturer and supplier based in Bangkok, Thailand, has built a solid reputation for delivering top-notch Aluminium 5005 Plates and Sheets. With years of experience and cutting-edge production facilities, this company ensures that their products not only meet international standards but also cater to the specific needs of their customers. The Aluminium 5005 Plates and Sheets from Wiraphan are highly valued for their impressive corrosion resistance, excellent formability, and visual appeal, making them perfect for anodizing and decorative finishes. By focusing on precision, durability, and timely delivery, Wiraphan provides dependable aluminium solutions to a wide range of industries, including construction, architecture, transportation, and marine engineering.
These Aluminium 5005 Plates and Sheets primarily consist of aluminium, with a small addition of magnesium—around 0.8%—which boosts their strength and resistance to corrosion. Typically, the composition includes about 97.8% aluminium, magnesium, and trace amounts of elements like iron, silicon, and copper. These sheets are known for their medium strength, great weldability, and good machinability. Their mechanical properties feature a tensile strength of roughly 145–185 MPa, a yield strength of about 110 MPa, and an elongation rate of 12–20%. Aluminium 5005 is particularly recognized for its excellent anodizing response, making it a fantastic choice for decorative and architectural applications.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Chemical Properties | % Value |
| Silicon (Si) | 0.30 |
| Chromium (Cr) | 0.10 |
| Manganese (Mn) | 0.20 |
| Magnesium (Mg) | 0.5-1.1 |
| Copper (Cu) | 0.20 |
| Titanium (Ti) | – |
| Iron (Fe) | 0.7 |
| Zinc (Zn) | 0.25 |
| Aluminium (Al) | Balance |
| Property | Value |
| Proof Stress | 120 Min MPa |
| Tensile Strength | 145 – 185 MPa |
| Elongation at 50 mm | 3 Min % |
| Hardness Brinell | 47 HB |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 5005 Plates and Sheets find extensive use across various industries thanks to their versatility and durability. In architecture, they are favored for curtain walls, roofing, siding, and decorative panels due to their ability to achieve stunning anodized finishes. In marine settings, they resist seawater corrosion, making them ideal for boat components and structural parts. The transportation sector utilizes them for body panels, trims, and automotive components. Moreover, they are commonly found in household appliances, signage, furniture, and packaging applications, ensuring reliability and longevity.
Yes, we offer custom sizes for Aluminium 5005 Plates and Sheets to meet specific project needs. Our team at Wiraphan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@wiraphansheetsplates.com.
| Standard | UNS | ISO | BS | DIN |
| 5005 | A95005 | AlMg1 | N41 | 3.3315 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Aluminium 5005 Sheets and Plates are widely used in applications requiring corrosion resistance and superior anodizing qualities. In construction, they are utilized for roofing, cladding, and building facades, offering durability and an appealing finish. The alloy is popular in the signage industry for creating durable and visually striking signs. In the marine sector, it is used for boat hulls and marine structures due to its resistance to saltwater corrosion. Aluminium 5005 is also employed in decorative panels, interior design, and automotive applications, combining strength, lightweight properties, and aesthetic appeal.
