Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, is well-known for its top-notch Hastelloy Sheets and Plates. The company focuses on providing nickel-based alloy products that adhere to international standards for corrosion resistance, strength, and durability. Hastelloy sheets and plates are particularly favored in highly corrosive settings because of their remarkable ability to withstand oxidizing and reducing agents, acids, and corrosion caused by chlorides. Wiraphan offers these sheets and plates in a variety of sizes and thicknesses, ensuring that customers receive reliable, precision-engineered materials suitable for chemical processing, petrochemical, marine, and other industrial applications that demand long-lasting, high-performance alloy solutions.
Hastelloy Sheets and Plates are primarily made of nickel, with notable amounts of molybdenum, iron, and small quantities of chromium, cobalt, and tungsten, depending on the specific grade (like C-22 or C-276). This meticulously controlled composition grants exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, all while maintaining impressive mechanical strength and ductility. In terms of mechanics, these sheets and plates boast tensile strength ranging from 485 to 690 MPa, yield strength around 240 to 310 MPa, and good elongation, ensuring dependable performance in both fabrication and operational settings.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grades | C276, C22, B2, B3, X |
| Hastelloy Plate Length | 0-12mm or as required |
| Specification of Hastelloy Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 0-2500mm or as required |
| Plate Thickness | 0.3 to 1200 mm or as required |
| Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| Plate Surface finish | Thickness (mm) | Width (max mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed plate | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled plate | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy Sheets and Plates find extensive use in chemical reactors, heat exchangers, piping systems, valves, and other equipment that face highly corrosive environments. Their outstanding corrosion resistance, toughness, and durability make them perfect for applications in chemical processing, petrochemical plants, marine equipment, and power generation industries. Hastelloy Sheets and Plates deliver a reliable, high-performance solution for sectors that require durable, corrosion-resistant, and mechanically robust nickel-based alloy materials.
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
Hastelloy sheets and plates are widely used in industries that require materials with exceptional corrosion resistance and durability. Common applications include chemical processing equipment such as reactors, heat exchangers, and piping systems. Where exposure to aggressive chemicals is frequent. They are also used in the aerospace industry for turbine engines and exhaust systems due to their high-temperature resistance. Other uses include pollution control systems, nuclear reactors and marine environments where their resistance to pitting, crevice corrosion, and oxidation ensures reliability and longevity in harsh conditions.
