Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality Copper Nickel 90/10 Angles. Known for their remarkable corrosion resistance, strength, and durability, these angles are perfect for tough marine, chemical, and industrial applications. Wiraphan is committed to precision manufacturing and rigorous quality control, ensuring that their Copper Nickel 90/10 Angles meet international standards. With exceptional resistance to seawater, biofouling, and acidic conditions, these angles are ideal for structural supports, piping frameworks, and fabrication projects that demand long-lasting reliability and top-notch performance.
| Specifications | : | ASTM B151 / ASME SB151 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Cu-Ni 70/30 Angle | : | 5mm to 9mm |
| Cu-Ni 70/30 Channel | : | 40mm*20mm~300mm*300mm |
| Cu-Ni 70/30 Beam | : | 3″ thru 12.31″ |
| Cu-Ni 70/30 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 90/10 | 2.0872 | C70600 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 90/10 Angles are extensively utilized in industries that require durable, corrosion-resistant, and high-performance structural components. In marine settings, they are used for piping supports, heat exchanger frameworks, condenser supports, and hull structures that come into contact with seawater. The chemical and petrochemical industries rely on them for pipelines, tank supports, and equipment that handle corrosive fluids. Additionally, they find applications in industrial machinery, fabrication projects, and electrical equipment that need high-strength, corrosion-resistant materials. Their blend of durability, corrosion resistance, and workability makes Copper Nickel 90/10 Angles a dependable choice for challenging industrial environments.
Copper nickel 90/10 angles are widely used in the marine and industrial industries due to their corrosion resistance and excellent durability. In shipbuilding it is used for hulls, sea water pipes and desalination equipment. They are ideal for offshore oil and gas platforms, heat exchangers and dense tubes in power plants. These corners are also used in chemical plants to deal with perishables. Furthermore, their resistance to biofouling makes them suitable for aquaculture and marine applications, providing reliable operation in harsh, saltwater environments.
