Wiraphan Sheets and Plates, a reputable manufacturer and supplier located in Bangkok, Thailand, specializes in providing top-notch Hastelloy C276 Coils and Slitting Coils for industries that demand outstanding corrosion resistance and mechanical performance. Crafted with precision and in line with international standards, these coils are known for their remarkable durability, high tensile strength, and ability to withstand both oxidizing and reducing agents in harsh chemical and high-temperature settings. The Hastelloy C276 Coils and Slitting Coils from Wiraphan find extensive applications in chemical processing, petrochemical, marine, and pollution control sectors. The company prides itself on timely deliveries, competitive pricing, and dependable customer support for clients both locally and internationally.
These Hastelloy C276 Coils and Slitting Coils are primarily made up of nickel (at least 57%), chromium (14.5–16.5%), and molybdenum (15–17%), with small amounts of tungsten, cobalt, and iron added in. This unique blend offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, all while maintaining impressive mechanical properties. In terms of mechanics, these coils deliver high tensile strength, toughness, fatigue resistance, ductility, and excellent formability, making them ideal for fabrication, precision engineering, and high-performance applications in challenging chemical environments.
| Specification | ASTM B575 / ASME SB575 |
|---|---|
| Thickness | Plate 0125″ to 5.00″ / Sheets 008″ to .0125″ |
| Sheet / Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheet / Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Sheets Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Plate / Sheets Size | 15NB to 150NB In |
| Tempers | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Coils Thickness | 0.3 mm to 120 mm |
| Coils Length | AS PER CUSTOMER’S REQUIREMENT |
| Form | Sheets, Plates, Coils, Strips, Circle, Ring, Disc, Foils |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Coil/Coil Type |
Sizes |
Availability |
|---|---|---|
| ASTM B575 Hastelloy C276 Coil |
0.4mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
0.5mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
0.8mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
1mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
1.2mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
1.6mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
2mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
3mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
4mm |
√ |
| Hastelloy C276 ASTM B575 Coil |
5mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
6mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
8mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
10mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
12mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
16mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
20mm |
√ |
| ASTM B575 Hastelloy C276 Coil |
25mm |
√ |
| Steel Coil |
Size (mm) |
Weight per Coil (Kg) |
Size(mm) |
Weight per Coil (Kg) |
|---|---|---|---|---|
| Hastelloy C276 Coil |
4000 x 2000 x 2.0 |
136.0 |
3000 x 1500 x 5.0 |
191.0 |
| Hastelloy C276 Coil |
4000 x 2000 x 3.0 |
204.0 |
4000 x 2000 x 5.0 |
340.0 |
| Hastelloy C276 Coil |
2500 x 1250 x 4.0 |
106.0 |
2500 x 1250 x 6.0 |
159.0 |
| Hastelloy C276 Coil |
3000 x 1500 x 4.0 |
153.0 |
3000 x 1500 x 6.0 |
230.0 |
| Hastelloy C276 Coil |
4000 x 2000 x 4.0 |
272.0 |
4000 x 2000 x 6.0 |
408.0 |
| Hastelloy C276 Coil |
2500 x 1250 x 5.0 |
133.0 |
Hastelloy C276 Coils and Slitting Coils are widely utilized in the production of heat exchanger tubing, reactor linings, piping components, flanges, and critical equipment that must endure highly corrosive and high-temperature conditions. They are also essential in offshore platforms, flue-gas desulfurization units, chemical reactors, and industrial scrubbers, where long-lasting durability and chemical resistance are crucial. The combination of superior corrosion resistance, mechanical reliability, and versatility makes Hastelloy C276 Coils and Slitting Coils the go-to choice for advanced industrial and engineering applications.
The Hastelloy C276 coil/slitting coil is widely used in applications requiring high corrosion resistance and strength. Applications include chemical processing, such as reactors, heat exchangers, piping systems using aggressive chemicals such as sulfuric acid, hydrochloric acid, chloride and are also used in containment devices pollution control, such as scrubbers and incinerators, in addition to resisting high temperatures and corrosive gases Due to its durability in harsh environments, this alloy is used used in aerospace applications, power generation systems and desalination plants The coiled form offers flexibility in various production processes.
