Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch Stainless Steel 310S Foils designed for high-temperature, industrial, and structural applications. With state-of-the-art production facilities and a commitment to international quality standards, Wiraphan guarantees products that excel in oxidation resistance, thermal stability, and mechanical strength. These Stainless Steel 310S Foils are crafted to perform reliably in high-temperature and moderately corrosive environments, making them perfect for furnace components, heat exchangers, petrochemical equipment, and industrial machinery. Thanks to their consistent quality, prompt delivery, and cost-effective solutions, Wiraphan has become a go-to partner for clients both locally and globally.
Stainless Steel 310S Foil is an austenitic stainless steel primarily made up of iron, 24–26% chromium, and 19–22% nickel, with a very low carbon content that enhances weldability and reduces carbide precipitation. Its high levels of chromium and nickel provide outstanding resistance to oxidation, scaling, and high-temperature corrosion. On the mechanical side, Stainless Steel 310S Foils boast excellent tensile strength, toughness, and thermal stability, along with good ductility and flexibility. These characteristics make 310S Foils ideal for precision forming, fabrication, and high-temperature structural applications in challenging industrial settings.
| Item | Stainless Steel 310s foil(Hot rolled, cold rolled) | |
| Thickness | 0.025 to 3 mm and as per Customer Requirement | |
| Width | 3 mm to 2000 mm and as per Customer Requirement | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
310s | 0.15 max | 5.5-7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | – | 0.3-0.5 | – |
| Properties | Metric | Imperial | |
| Tensile strength (transverse at room temperature) | 685 MPa | 99400 psi | |
| Tensile strength (longitudinal at room temperature) | 696 MPa | 101000 psi | |
| Yield strength (transverse at room temperature) | 292 MPa | 42400 psi | |
| Yield strength (longitudinal at room temperature) | 310s MPa | 43700 psi | |
| Compressive yield strength | 365 MPa | 52900 psi | |
| Elastic modulus | 197 GPa | 28573 ksi | |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 | |
| Elongation at break (longitudinal at room temperature) | 56% | 56% | |
| Elongation at break (transverse at room temperature) | 62.50% | 62.50% | |
| Hardness, Rockwell B (transverse at room temperature) | 85 | 85 | |
| Hardness, Rockwell B (longitudinal at room temperature) | 85 | 85 |
Industries that demand exceptional high-temperature performance and oxidation resistance widely utilize Stainless Steel 310S Foils. In chemical and petrochemical plants, they are commonly found in heat exchangers, furnace linings, and processing equipment. In power generation and industrial furnaces, they serve as burner components, boiler parts, and exhaust systems. Their unique combination of toughness, thermal stability, and long-lasting performance ensures dependable operation in demanding industrial, structural, and high-temperature applications.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 310s | 1.4845 | S31008 | SUS 310S | – | – | – | – |
SS 310S Foils are widely used in high-temperature environments due to their excellent resistance to oxidation and corrosion. Common applications include heat exchangers, furnace components, and thermal processing equipment. They are also used in the manufacturing of chemical reactors, gas turbines, and industrial ovens, where high strength and thermal stability are crucial. Additionally, 310S Foils are utilized in food processing, petrochemical, and power generation industries. Their ability to withstand extreme temperatures and harsh conditions makes them ideal for critical components in aerospace, automotive, and energy sectors.
