Duplex Steel S32205 sheets and plates are top-notch stainless steel products celebrated for their remarkable blend of strength and resistance to corrosion. As a duplex stainless steel, S32205 features a well-balanced microstructure of austenite and ferrite, which provides it with mechanical strength that’s nearly double that of standard austenitic stainless steels. It also boasts excellent resistance to localized corrosion, including issues like pitting, crevice corrosion, and stress corrosion cracking. These plates find their place in demanding environments such as marine, chemical, oil & gas, and pulp & paper industries, where durability and reliability are non-negotiable.
The chemical makeup of S32205 generally includes 22% chromium, 5–6% nickel, 3% molybdenum, along with carefully controlled amounts of nitrogen, manganese, and silicon. This specific alloying process boosts its corrosion resistance, particularly in environments rich in chlorides. Duplex S32205 delivers a minimum yield strength of 450 MPa and a tensile strength of 620 MPa, along with impressive toughness and weldability. It retains its mechanical properties even in extreme cold and high-pressure situations, making it a fantastic choice for structural and pressure-related applications.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205 offer a combination of high strength and excellent corrosion resistance, making them ideal for harsh environments. Their balanced microstructure of austenite and ferrite enhances resistance to stress corrosion cracking, pitting, and crevice corrosion. With superior mechanical properties, including high tensile strength and yield strength, S32205 is highly durable and reliable. These plates also offer excellent weldability and formability, making them versatile for various industrial applications such as chemical processing, offshore, and marine industries. They provide a cost-effective alternative to more expensive high-alloy steels in demanding conditions.
Yes, we offer custom sizes for Duplex Steel Sheet and Plates S32205 to meet specific project needs. Our team at Wiraphan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@wiraphansheetsplates.com.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex Steel Sheet and Plates S32205 are widely used in industries that require high strength and corrosion resistance. Common applications include chemical processing, oil and gas exploration, and marine environments, where resistance to pitting, crevice corrosion, and stress corrosion cracking is essential. S32205 plates are used in heat exchangers, pressure vessels, storage tanks, and offshore platforms. They are also ideal for desalination plants, pulp and paper mills, and structural components exposed to harsh environments. Their durability and versatility make them a preferred choice for demanding applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
