If you’re looking for top-notch EN8 Sheets and Plates, look no further than Wiraphan Sheets and Plates, a premier manufacturer and supplier based in Bangkok, Thailand. These high-quality sheets and plates are crafted to cater to the varied demands of the engineering and industrial sectors. EN8, a medium carbon steel grade, is celebrated for its impressive tensile strength, wear resistance, and machinability. You’ll find these sheets and plates are perfect for applications that need a solid balance of strength and toughness, all without the hassle of complex heat treatments. They come in a range of sizes and thicknesses, and are produced to meet international standards, guaranteeing durability and reliability for those critical applications.
The composition of EN8 Sheets and Plates includes carbon (0.36–0.44%), manganese (0.60–1.0%), along with trace amounts of silicon, sulfur, and phosphorus, with iron making up the rest. This blend strikes a great balance between strength, hardness, and toughness. On the mechanical side, EN8 boasts a tensile strength of 550–700 MPa and a yield strength of around 280–350 MPa, along with moderate elongation. These characteristics make EN8 a versatile choice for general engineering tasks that require both strength and ease of machining.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Mn | P | S | Si |
| 0.35 TO 0.45 | 0.60 TO 1.00 | 0.06 max | 0.06 max | 0.05 – 0.30 |
| Grade | HEAT TREATMENT | CORRESPONDING SPECIFICATION | |||||
| Hardening Temperature | Quenching Medium | Tempering Temperature | Brinell Rock well hardness | JAPAN JIS | AISI | POLDI THREAD | |
| EN-8 | 750-900 | OIL | 150-200 | – | – | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Wiraphan Sheets and Plates based in Bangkok, Thailand, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
| EN8 Equivalents | |
|---|---|
| BS970: 1955 | EN8 |
| BS970/PD970: 1970 onwards | 080M40 |
| European | C40, C45, Ck40,Ck45, Cm40, Cm45 |
| Werkstoff No. | 1.0511, 1.1186, 1.1189 |
| US SAE (AISI) | 1039, 1040, 1042, 1043, 1045 |
You’ll find EN8 Sheets and Plates used in a variety of applications, including automotive components, gears, axles, shafts, studs, bolts, spindles, and other general engineering parts. Their robust strength and wear resistance make them ideal for medium-duty applications where performance and durability are key. Plus, EN8 can be surface-hardened to enhance wear resistance, broadening its use in heavy engineering and industrial machinery. With EN8 Sheets and Plates, industries gain a reliable and cost-effective solution for crafting strong and dependable components.
Yes, we offer custom sizes for EN8 Sheet and Plates to meet specific project needs. Our team at Wiraphan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@wiraphansheetsplates.com.
EN8 sheets and plates are medium carbon steel products known for excellent strength, toughness and machinability. It is commonly used in the manufacture of automotive parts, gears, axles, shafts and crankshafts due to its corrosion resistance. These materials are also used in industrial applications that require good tensile strength, such as machine tools, bolts and studs. In addition, EN8 plates are suitable for construction applications, including bridges and construction equipment. Their versatility makes them ideal for moderate stress and heat treatment system applications.
