Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, offers top-notch Haynes 25 / L605 Foil for critical industrial applications. This cobalt-based superalloy is celebrated for its remarkable strength, exceptional resistance to corrosion, and impressive oxidation resistance at high temperatures. Haynes 25 / L605 Foil finds its place in various sectors, including aerospace, power generation, chemical processing, and marine industries, where lightweight yet robust materials are essential. Available in a range of thicknesses and sizes, these foils are meticulously engineered to comply with international standards, ensuring reliability and performance even in the toughest service conditions.
The composition of Haynes 25 / L605 Foil features cobalt as the base, with notable additions of chromium (20%), tungsten (15%), and nickel (10%), along with trace amounts of iron, manganese, and carbon. This distinctive blend grants it excellent oxidation resistance up to 1093°C (2000°F) and outstanding wear resistance in challenging environments. On the mechanical side, it boasts a tensile strength of around 930 MPa, a yield strength of about 370 MPa, and good elongation, which guarantees toughness and durability even under extreme thermal and mechanical stress.
| Standard | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
| STANDARD | Material No | EN Designation | UNS | Alloy |
| Haynes 25 / L605 | 2.4964 | CoCr20W15Ni | R30605 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes 25 / L605 Foil is extensively utilized in aerospace components, turbine engine parts, combustion chambers, heat exchangers, chemical processing equipment, and medical implants. Its superior resistance to high-temperature oxidation, sulfidation, and wear makes it an ideal choice for environments where other materials might falter. Additionally, its biocompatibility and durability make it suitable for surgical instruments and implants. Haynes 25 / L605 Foil delivers a reliable, high-performance solution for industries facing demanding applications involving heat, corrosion, and mechanical stress.
Haynes 25 (L605) foil is a cobalt-based alloy known for high strength, good oxidation properties, and excellent performance at high temperatures It is commonly used in the aerospace, chemical, and electrical industries. Its main applications include turbine blades, combustion chambers, exhaust systems, and heat exchangers, where it is resistant to extreme temperatures and environmental corrosion in addition to being used in springs, fasteners and materials renewal in high pressure and high temperature conditions. Its resistance to oxidation and wear makes it ideal for critical high-performance applications.
