Wiraphan Sheets and Plates, a reputable manufacturer and supplier located in Bangkok, Thailand, proudly offers top-notch Inconel 625 Coil and Slitting Coil designed for high-performance applications in industries like aerospace, chemicals, and more. Crafted with precision and a commitment to international standards, these coils boast remarkable corrosion resistance, impressive tensile strength, and durability even in extreme temperatures and tough environments. The Inconel 625 Coil/Slitting Coil from Wiraphan is a go-to choice in sectors where materials face thermal cycling, mechanical stress, and harsh corrosive conditions. With a strong emphasis on timely delivery, competitive pricing, and outstanding customer support, the company guarantees a reliable supply for both local and international clients.
The Inconel 625 Coil/Slitting Coil is primarily made up of nickel (at least 58%), chromium (20–23%), molybdenum (8–10%), and iron (maximum 5%), along with trace amounts of niobium, cobalt, and other elements. This unique blend offers exceptional resistance to oxidation, pitting, and stress corrosion cracking, while also ensuring excellent tensile strength, toughness, and fatigue resistance at high temperatures. Mechanically, these coils are characterized by high ductility, formability, and dimensional stability, making them perfect for forming, slitting, and precision fabrication in demanding applications.
Specifications : ASTM B443 / ASME SB443
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled (HR), Cold rolled coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Coils, Shim Coils, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | N |
| Inconel Alloy 625 | 0.10 max | 0.50 max | 0.50 max | – | 0.15 min | 20.0–23.0 | 5.0 max | 58.0 min | – |
| Density | Melting Point | Tensile Strength | Yield Strength 0.2% Proof | Elongation (% in 50mm) (thick.>0.76mm) |
| 8.4 g/cm3 | 1.350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Grade | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Inconel 625 Coil/Slitting Coil finds extensive use across various industries, including aerospace, marine, chemical processing, oil and gas, and power generation. They are particularly well-suited for manufacturing turbine components, heat exchanger parts, fasteners, gaskets, and other high-performance equipment that must withstand corrosive or high-temperature environments. Additionally, these coils are utilized in offshore platforms, chemical reactors, and industrial machinery where durability, mechanical strength, and corrosion resistance are essential. The combination of high-temperature performance, mechanical reliability, and corrosion resistance makes Inconel 625 Coil/Slitting Coil a top choice for advanced applications.
Inconel 625 coil and slitting coil are highly versatile materials used in demanding applications where high strength, excellent corrosion resistance, and durability are required. Due to their superior resistance to oxidation, pitting, and crevice corrosion, they are widely used in industries such as chemical processing, aerospace, marine, and nuclear power. Applications include components for reactors, heat exchangers, and gas turbines, making them ideal for extreme environments where extreme temperatures and corrosive conditions are present.
