Wiraphan Sheets and Plates, located in the vibrant city of Bangkok, Thailand, has built a solid reputation as a trusted manufacturer and supplier of top-notch metal products, particularly Nickel Alloy 200 Sheets and Plates. Renowned for their precision, reliability, and commitment to international standards, Wiraphan caters to industries that require exceptional corrosion resistance along with outstanding thermal and mechanical performance. Nickel Alloy 200 is a nearly pure nickel material, specifically crafted for applications where it’s crucial to withstand both reducing and oxidizing environments. The company prides itself on strict quality control, cutting-edge production methods, and prompt delivery, ensuring that their sheets and plates meet the highest industrial and engineering standards.
Nickel Alloy 200 stands out as a nearly pure nickel product with very few impurities, providing remarkable corrosion resistance, high ductility, and excellent thermal and electrical conductivity. It boasts good mechanical strength at both room temperature and elevated conditions, maintaining stability even when exposed to harsh chemical environments for extended periods. Its unique blend of toughness, malleability, and resistance to various corrosive agents makes it an ideal choice for critical industrial applications where reliability and longevity are essential.
| Specification | ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| standards and approvals |
|
| Plasma profiles | As per customer’s drawings |
| Value added services | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| VAS |
|
| Packing | Bundles with waterproof cloth outside or plywood box |
| Test | UT, SGS testing, TUV etc |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | —2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Nickel Alloy 200 Sheets and Plates commonly used in chemical processing equipment, including tanks, piping, heat exchangers, and evaporators, where robust resistance to acids and alkalis is a must. They’re also utilized in marine settings, electronics, and the food processing industry thanks to their impressive corrosion resistance and formability. Furthermore, Nickel Alloy 200 is applied in aerospace, energy, and high-temperature industrial components. Its versatility, durability, and resistance to chemical attack guarantee reliable performance in even the most demanding industrial and engineering environments.
| Nickel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874″) x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135″) x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120″) x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120″) x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120″) x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120″) x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120″) x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105″) x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105″) x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105″) x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075″) x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075″) x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060″) x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060″) x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060″) x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060″) x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048″) x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048″) x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036″) x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036″) x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030″) x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030″) x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030″) x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024″) x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024″) x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018″) x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018″) x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015″) x 36 x 120 | .6300 | 18.90 |
Nickel Alloy 200 sheets and plates are widely used in industries requiring high corrosion resistance and excellent mechanical properties. Common applications include chemical processing equipment, such as heat exchangers, reactors, and piping systems, particularly in environments with acidic or alkaline conditions. Due to their resistance to oxidation and high-temperature stability, they are also used in the food and beverage industry, aerospace components, and power generation systems. Additionally, they are employed in manufacturing electrical and electronic components, providing superior conductivity and strength.
