SA 516 grade 60 Sheets and Plates

Wiraphan Sheets and Plates, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality SA 516 Grade 60 Sheets and Plates. These products are celebrated for their remarkable strength, durability, and performance, especially in high-pressure and high-temperature environments. Crafted with cutting-edge manufacturing techniques and rigorous quality control, these sheets and plates adhere to international standards, guaranteeing dependable quality and consistent performance. Wiraphan is committed to delivering steel solutions that blend exceptional structural integrity, toughness, and precision, making them perfect for critical applications in boilers, pressure vessels, and power generation equipment where safety, long-term performance, and heat resistance are paramount.

SA516 Grade 60 Pressure Vessel Plates Thailand, ASTM A516 Grade 60 Boiler Quality Plates Thailand, SA516 Gr 60 BQ Plates Bangkok, SA 516 Gr 60 Hot Rolled Boiler Steel Plates Pattaya, ASTM A516 Gr 60 Plates Chiang Mai, SA516 Gr.60 Boiler Steel Plates Rayong, A516 Grade 60 Boiler Plates Distributor Nonthaburi, ASME SA 516 Gr 60 Boiler & Pressure Vessel Stockist in Bangkok, Thailand.

ASME SA516 Gr 60 Carbon Steel Plate

SA 516 Lower Temperature Carbon Steel Grade 60 Plates

A516 Grade 60 HR Boiler Plates

ASME SA516 Gr 60 Carbon Steel Plate Thailand, SA 516 Lower Temperature Carbon Steel Grade 60 Plates Dealer Thailand, A516 Grade 60 HR Boiler Plates Bangkok, ASTM A516 Gr 60 Boiler Plates Exporter Pattaya, SA 516 Gr 60 Carbon Steel Pressure Vessel Plates Chiang Mai, SA516 Grade 60 Pressure Vessel & Boiler Plates Supplier in Rayong, SA285 Gr.A Boiler Steel Plates Nonthaburi.

SA 516 Grade 60 is a carbon steel plate tailored for moderate to high-temperature service. Its typical composition includes carbon (up to 0.27%), manganese (0.85–1.20%), phosphorus (≤0.035%), and sulfur (≤0.035%). This chemical makeup results in outstanding mechanical properties, featuring a minimum yield strength of 260 MPa, tensile strength ranging from 415 to 550 MPa, and impressive impact toughness. The steel is not only easy to weld and form but also maintains its strength and structural stability at elevated temperatures, ensuring reliable performance in demanding industrial settings.

SA 516 grade 60 Sheets and Plates Specification

Grade : ASME SA 516 GR.60 Boiler and Pressure Vessel Steel Plates
Width : 1250mm-3000mm
Thickness : 3mm-600mm
Length : 3000mm-11000mm
Production : Hot-Rolled (HR)
Heat Treatment : Rolled / Normalised/N+T/QT

Chemical Composition Of SA 516 grade 60 Sheets and Plates

C	Si	Mn	P	S	Al	Cr	Cu	Ni	Mo	Nb	Ti	V
0.18	0.4	0.95/1.50	0.015	0.008	0.02 (Min)	0.3	0.3	0.3	0.08	0.01	0.03	0.02

Mechanical Properties Of SA 516 grade 60 Sheets and Plates

Tensile strength (ksi)	Yield strength (ksi)	Elongation min, % 200 mm (8 in)	Elongation min, % 50 mm (2 in)
485-620 (70-90)	260 (38)	17	21

SA516 Grade 60 Pressure Vessel Plates Thailand, ASTM A516 Grade 60 Boiler Quality Plates Thailand, SA516 Gr 60 BQ Plates Bangkok, SA 516 Gr 60 Hot Rolled Boiler Steel Plates Pattaya, ASTM A516 Gr 60 Plates Chiang Mai, SA516 Gr.60 Boiler Steel Plates Rayong, A516 Grade 60 Boiler Plates Distributor Nonthaburi, ASME SA 516 Gr 60 Boiler & Pressure Vessel Stockist in Bangkok, Thailand.

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest SA 516 grade 60 Sheets and Plates Manufacturer and Exporter in Bangkok, Thailand

Wiraphan Sheets and Plates based in Bangkok, Thailand, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

ASME SA516 Gr 60 Steel Plate Thailand, SA 516 Lower Temperature Carbon Steel Grade 60 Plates Dealer Thailand, A516 Grade 60 HR Boiler Plates Bangkok, ASTM A516 Gr 60 Boiler Plates Exporter Pattaya, SA 516 Gr 60 Carbon Steel Pressure Vessel Plates Chiang Mai, SA516 Grade 60 Pressure Vessel & Boiler Plates Supplier in Rayong, SA285 Gr.A Boiler Steel Plates Nonthaburi.

SA 516 Grade 60 Sheets and Plates find extensive use in power plants, pressure vessels, boilers, heat exchangers, and the petrochemical industry. They are perfect for storage tanks, structural components, and equipment that face high temperatures and pressure. Moreover, these sheets and plates are utilized in industrial machinery and heavy-duty construction projects where high strength, toughness, and heat resistance are essential. With their blend of durability, mechanical strength, and heat resistance, SA 516 Grade 60 Sheets and Plates from Wiraphan Sheets and Plates offer long-lasting, efficient, and reliable solutions for a wide range of industrial and structural applications.

Types of SA 516 grade 60 Sheets and Plates

Are Custom Sizes Available for SA 516 grade 60 Sheets and Plates?

Yes, we offer custom sizes for SA 516 grade 60 Sheets and Plates to meet specific project needs. Our team at Wiraphan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@wiraphansheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of SA 516 grade 60 Sheets and Plates

SA 516 Grade 60 Sheets and Plates are widely used in the fabrication of pressure vessels, boilers, and heat exchangers, especially in industries that require materials capable of withstanding moderate to low temperatures. They are commonly used in the oil, gas, petrochemical, and power generation sectors for applications involving storage tanks, reactors, and piping systems. The plates are ideal for manufacturing pressure vessels, boilers, and other heavy-duty equipment, offering reliable performance in environments where strength, durability, and resistance to pressure are critical.
