Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch Stainless Steel 316L Angles designed for a variety of industrial, chemical, and structural applications. With state-of-the-art production facilities and a commitment to international quality standards, Wiraphan guarantees products that excel in corrosion resistance, durability, and thermal stability. These Stainless Steel 316L Angles are specifically crafted to endure harsh corrosive environments and high temperatures, making them perfect for industries like chemical processing, petrochemical, marine, and food processing. Thanks to their consistent quality, prompt delivery, and cost-effective solutions, Wiraphan has become a go-to supplier for clients both locally and around the globe.
Stainless Steel 316L Angle is an austenitic stainless steel primarily made up of iron, 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, featuring low carbon content to improve weldability and reduce sensitization. This unique composition offers outstanding resistance to pitting, crevice corrosion, and intergranular corrosion, especially in harsh, chloride-rich environments. On the mechanical side, Stainless Steel 316L Angles provide good tensile strength, toughness, and ductility, along with excellent thermal stability and weldability. These characteristics make 316L Angles ideal for fabrication, forming, and structural applications in demanding industrial and chemical settings.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| SS 316Ti | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Wiraphan Sheets and Plates based in Bangkok, Thailand, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless Steel 316L Angles find extensive use in industries that demand high corrosion resistance and long-lasting performance. In chemical and petrochemical plants, they are commonly used in piping systems, tanks, and heat exchangers. In marine and offshore settings, they serve as structural supports and components that are regularly exposed to saltwater. In industrial applications, Stainless Steel 316L Angles are utilized in food processing, pharmaceutical equipment, and power generation machinery. Their blend of strength, corrosion resistance, and durability ensures reliable and safe operation in challenging industrial, structural, and chemical environments.
| THICKNESS | ||||||
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless steel 316Ti angles are widely used in applications requiring corrosion resistance and high temperature performance. Their titanium-stable structure prevents sensitivity, making them ideal for chloride exposure and harsh chemicals, such as the chemical, marine and petrochemical industries These angles are used structurally applications, support frameworks and reinforcing components among them due to their excellent mechanical properties and durability Occurs in heat exchangers, pressure vessels and piping systems where there is increased resistance to oxidation and scaling at high temperatures is important.
