Wiraphan Sheets and Plates, located in Bangkok, Thailand, is a trusted manufacturer and supplier of top-notch steel products, including SA537 Class 2 Boiler Sheets and Plates. With a focus on pressure vessel and boiler-grade steels, Wiraphan delivers materials specifically designed for high-temperature and high-pressure applications. These SA537 Class 2 plates are crafted to meet ASME standards, ensuring they provide exceptional strength, toughness, and weldability, making them perfect for demanding industrial uses. Wiraphan is dedicated to quality and compliance, catering to industries like petrochemical, power generation, and oil & gas.
The SA537 Class 2 Boiler Sheets and Plates are constructed from quenched and tempered carbon-manganese-silicon steel. This particular grade boasts impressive mechanical properties, featuring a minimum yield strength of 485 MPa and a tensile strength that ranges from 620 to 795 MPa. The steel is known for its excellent notch toughness, making it suitable for high-pressure vessels and boilers that require superior strength. Additionally, it offers good weldability, allowing for fabrication processes like forming, cutting, and welding without sacrificing structural integrity under high stress and temperature.
Grade : ASME SA 537 CL.2 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Tensile (MPa) | Yield (MPa) | Elongation |
| SA537 Class 2 | Quenched and tempered | 550–690 | 415 | 22% |
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These SA537 Class 2 Boiler Sheets and Plates are extensively used in the construction of pressure vessels, heat exchangers, reactors, and industrial boilers that operate under high-pressure and high-temperature conditions. They find common application in the oil & gas sector, power plants, and chemical processing facilities. Thanks to their high strength and resistance to brittle fracture, they are ideal for critical structural components in large-scale equipment. Their remarkable toughness and durability also make SA537 Class 2 plates a preferred choice in scenarios where reliability and a long service life are crucial.
SA537 Class 2 Boiler Sheet and Plate are primarily used to construct pressure vessels and boilers, especially in industries dealing with high-temperature and high-pressure environments. They are commonly found in power plants, refineries, chemical processing facilities, and steam generation systems. Their high strength and excellent resistance to thermal stress, cracking, and corrosion make them suitable for critical applications where durability and reliability are paramount. The material is also utilized to manufacture heat exchangers, storage tanks, and industrial piping systems.
