Wiraphan Sheets and Plates, located in Bangkok, Thailand, stands out as a top manufacturer and supplier of high-quality stainless steel products, particularly Stainless Steel 17-4 PH Sheets and Plates. With a strong focus on quality and precision, Wiraphan crafts these sheets and plates to deliver impressive strength, outstanding corrosion resistance, and solid mechanical properties. Utilizing advanced manufacturing techniques and top-notch raw materials, their products adhere to international standards and cater to a wide range of industries, including aerospace, chemical, and marine, ensuring dependable performance even in the toughest conditions.
Stainless Steel 17-4 PH Sheets and Plates are a type of precipitation-hardening stainless steel, made up of about 17% Chromium and 4% Nickel, along with Copper, Columbium (Niobium), and other elements that boost strength and hardness. This alloy typically boasts tensile strength ranging from 930 MPa to over 1,300 MPa, depending on the heat treatment, while also offering excellent yield strength and decent ductility. Thanks to its unique chemical makeup and heat treatability, this material exhibits superior corrosion resistance, high fatigue strength, and good toughness, making it ideal for high-performance and structural applications.
| Grade | Stainless Steel 17-4 PH | UNS S17400 |
| Standard | ASTM B625 / ASME SB625 |
| Thickness | 0.1mm To 100 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
| Applications | Off-Shore Oil Drilling Companies, Power Generation, Petrochemicals, Gas Processing, Specialty Chemicals, Pharmaceuticals, Pharmaceutical Equipment, Chemical Equipment, Sea Water Equipment, Heat Exchangers, Condensers, Pulp and Paper Industry |
| Cr | Mn | Si | Ni | P | S | C | Cu | cb+Ta | |
| MIN | 15 | – | – | 3 | – | – | – | 3 | 0.15 |
| Max | 17.5 | 1 | 1 | 5 | 0.04 | 0.03 | 0.07 | 3.5 | 0.45 |
| UTS (Tensile) Ksi (Mpa) | .02% Yield Strength Ksi (Mpa) | Elongation % in 2” (51mm) | Hardness Rockwell C |
| 160 | 145 | 5 | 35 |
| (1103) | (1000) |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 17-4 PH Sheets and Plates offer numerous advantages, including high strength, excellent corrosion resistance, and outstanding toughness, even in challenging environments. DIN 1.4542 Sheets and Plates are heat-treatable, allowing customization of mechanical properties to suit specific applications. These sheets exhibit superior resistance to stress corrosion cracking and pitting, making them ideal for marine and chemical environments. Their exceptional weldability and ease of fabrication simplify manufacturing processes. With excellent performance at moderate to high temperatures, they are widely used in aerospace, petrochemical, and food processing industries, ensuring reliability, durability, and long service life in demanding
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| Stainless Steel 17-4 PH 1D – Hot rolled, heat treated, pickled Plate & Sheet | 2.4–12.7 | max. 2032 |
| 2R – Stainless Steel 17-4 PH Cold-rolled, bright-annealed Sheet & Plate | 0.05–1.50 | 3–649 |
| 2H – Stainless Steel 17-4 PH Work hardened Plate & Sheet | 0.05–1.50 | 3–630 |
| 2B – Stainless Steel 17-4 PH Cold rolled, heat treated, pickled, skin passed Sheet & Plate | 0.25–8.0 | max. 2032 |
| 2D – Stainless Steel 17-4 PH Cold rolled, heat treated, pickled Plate & Sheet | 0.4–6.35 | max. 1524 |
| 2E – Stainless Steel 17-4 PH Cold rolled, heat treated, mechanically descaled Sheet & Plate | 0.4–8.0 | max. 2032 |
| 2R – Stainless Steel 17-4 PH Cold rolled, bright annealed Plate & Sheet | 0.25–3.5 | max. 1524 |
| 2H – Stainless Steel 17-4 PH Work hardened Sheet & Plate | 0.4–6.35 | max. 1524 |
| Stainless Steel 17-4 PH Polished, brushed Plate & Sheet | 0.5–4.0 | max. 1524 |
| Deco | 0.3–3.5 | max. 1524 |
| Stainless Steel 17-4 PH Coil | 0.30–3.5 | max. 1,524 |
Yes, we offer custom sizes for Stainless Steel 17-4 PH Sheet and Plates to meet specific project needs. Our team at Wiraphan Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@wiraphansheetsplates.com.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
These Stainless Steel 17-4 PH Sheets and Plates find extensive use in aerospace components, chemical processing equipment, marine hardware, and the petrochemical industry, where both high strength and corrosion resistance are essential. Common applications include turbine blades, shafts, fasteners, valves, and structural parts that face harsh environments and mechanical stress. The versatility of heat treating 17-4 PH stainless steel to achieve various strength levels provides design flexibility and reliability. Additionally, it’s frequently utilized in medical instruments, architectural projects, and other areas that demand durable, high-performance materials.
