Wiraphan Sheets and Plates, a prominent manufacturer and supplier based in Bangkok, Thailand, is dedicated to crafting top-notch Stainless Steel 410 Sheets and Plates tailored for structural, industrial, and engineering needs. With state-of-the-art production facilities and a commitment to international quality standards, Wiraphan guarantees products that boast exceptional strength, durability, and wear resistance. These Stainless Steel 410 Sheets and Plates are engineered to perform reliably in moderately corrosive environments and under mechanical stress, making them perfect for construction, automotive, machinery, and various industrial applications. Thanks to their consistent quality, timely delivery, and cost-effective solutions, Wiraphan has earned a reputation as a trusted partner for clients both locally and globally.
Stainless Steel 410 Sheets and Plates are a type of martensitic stainless steel, primarily made up of iron, 11.5–13.5% chromium, and a controlled amount of carbon, along with trace elements of manganese and silicon. This unique blend results in remarkable hardness, moderate corrosion resistance, and impressive tensile strength. On the mechanical side, Stainless Steel 410 showcases good wear resistance, ductility, and toughness, and it can be heat-treated to boost its hardness and strength even further. Its mix of mechanical properties, formability, and corrosion resistance makes it an excellent choice for structural, industrial, and engineering applications where durability and reliability are essential.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Cr | Mn | Si | Ni | C | P | S | Fe |
| SS 410 | 11.50 – 13.50 | 0.0 – 1.50 | 0.0 – 1.00 | 0.0 – 0.75 | 0.08 – 0.15 | 0.0 – 0.04 | 0.0 – 0.02 | Balance |
| Tensile Strength Ksi (Mpa) | 0.2% Offset Yield Strength Ksi (Mpa) | Elongation, % in 2″ (51 mm) | Hardening Response HRC | HRB |
| 65 (450) – 74 (510) | 30 (205) – 42 (290) | 20 – 34 | 38-45 | 82-96 |
| Grade | WERKSTOFF NR. | UNS | AISI | BS | SIS | EN | JIS | AFNOR |
| SS 410 | 1.4006 | S41000 | 410 | 410S21 | 2302 | X12Cr13 | 410 | Z10C13/Z13C13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 410 sheets and plates offer a variety of benefits including excellent hardness and corrosion resistance, making them ideal for hard-wearing components such as cutlery, fasteners and valves especially in soft corrosive environments moderate corrosion resistance due to chromium content. Their high strength and durability enable them to be used in buildings and mechanical components. In addition, they can be heat treated, increasing the mechanical properties. Simple and affordable devices further enhance their appeal, making them a great choice for industries such as automotive, aerospace and construction.
Across various industries, Stainless Steel 410 Sheets and Plates are highly valued for their strength, hardness, and moderate corrosion resistance. In construction, they find use in frameworks, support structures, and reinforcements. In the automotive industry, they are utilized in shafts, brackets, and exhaust components. Industrially, these sheets and plates are integral to machinery components, tools, and equipment that face wear and mechanical stress. Their well-rounded toughness, formability, and durability make them a reliable option for long-lasting performance in demanding engineering environments.
sed in applications requiring strength, corrosion resistance and moderate corrosion protection. Typical applications include utensils, surgical instruments and kitchen utensils for hardness and durability. Used in the automotive and aerospace industry for shafts, bolts, valves and other parts. In construction, it is used in building materials and packaging. Their heat resistance makes them suitable for furnace parts and petrochemical applications. In addition, they make a profit on mining and manufacturing machinery and equipment.
