Wiraphan Sheets and Plates, a prominent manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch Stainless Steel 422 Sheets and Plates tailored for industrial, structural, and engineering needs. With state-of-the-art production facilities and a commitment to international quality standards, Wiraphan guarantees products that boast exceptional durability, wear resistance, and moderate corrosion resistance. The Stainless Steel 422 Sheets and Plates are crafted to deliver reliable performance in mechanical, automotive, and industrial settings where high strength and hardness are essential. Thanks to their consistent quality, prompt delivery, and cost-effective solutions, Wiraphan has become a trusted partner for clients both locally and globally.
| Specifications : | ASTM A240 / ASME SA 240 |
| Dimensions : | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, IS & Custom Chemistry |
| Production Route : | Hot Rolled, Cold Rolled |
| Size : | Width from 100mm to 3000mm ; Length from 500mm to 12000mm |
| Thickness : | 0.1mm to 400mm |
| Delivery Condition : | As Rolled, Annealed, Quenched and Tempered, Normalized |
| Surface Finish : | Plain, Brushed, Cladded |
| Grade | C | P | Si | Ni | V | Fe | Mn | S | Cr | Mo | W | Cu |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SS 422 | 0.20-0.25 | 0.040 max | 0.20-0.60 | 0.50-1.0 | 0.17-0.30 | Bal | 1.0 | 0.030 max | 11.0-13.5 | 0.75-1.25 | 0.75-1.25 | 0.50 |
| Material | Condition | 0.2 % Yield Strength (ksi) | Ultimate Tensile Strength (ksi) | % Elongation in 2″ | % Reduction of Area | Hardness HB |
|---|---|---|---|---|---|---|
| SS 422 | Hardened & Tempered (AMS 5655) | 140 | 115 | 13 | 25 | 293-341 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| SS 422 | 1.4935 | S42200 |
| Density (lb / cu. in.) | 0.287 |
| Specific Gravity | 7.94 |
| Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | 0.12 |
| Electrical Resistivity (microhm-cm (at 68 Deg F)) | 432 |
| Melting Point (Deg F) | 2590 |
| Modulus of Elasticity Tension | 28 |
| METAL GAUGE | (APPROXIMATE INCHES) | NOMINAL DECIMAL (+/- INCHES) |
|---|---|---|
| 7 | 0.1793 | 0.0080 |
| 8 | 0.1644 | 0.0080 |
| 9 | 0.1495 | 0.0080 |
| 10 | 0.1345 | 0.0070 |
| 11 | 0.1196 | 0.0050 |
| 12 | 0.1046 | 0.0050 |
| 13 | 0.0897 | 0.0050 |
| 14 | 0.0747 | 0.0040 |
| 15 | 0.0673 | 0.0040 |
| 16 | 0.0598 | 0.0030 |
| 17 | 0.0538 | 0.0030 |
| 18 | 0.0478 | 0.0030 |
| 19 | 0.0418 | 0.0030 |
| 20 | 0.0359 | 0.0030 |
| 21 | 0.0329 | 0.0025 |
| 22 | 0.0299 | 0.0020 |
| 23 | 0.0269 | 0.0020 |
| 24 | 0.0239 | 0.0020 |
| 25 | 0.0209 | 0.0015 |
| 26 | 0.0179 | 0.0015 |
| 28 | 0.0149 | 0.0010 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 422 sheets and plates offer many advantages, including excellent increased strength and oxidation resistance, making them ideal for applications in harsh environments such as turbine heat exchangers They provide excellent corrosion resistance , ensure durability under extreme conditions Their high tensile strength and strength enhance the reliability of the structures, while mechanical practicality and ease of manufacture. These sheets and plates remain stable and durable under stress, providing longevity. In addition, the cost-effectiveness and compatibility of heat treatments provides assets tailored to specific industrial applications, resulting in versatile and reliable products.
These Stainless Steel 422 Sheets and Plates find extensive use in industries that prioritize strength, hardness, and moderate corrosion resistance. In the automotive field, they are utilized in shafts, gears, engine components, and parts of exhaust systems. In construction and engineering, they serve as vital materials for structural frameworks, reinforcements, and machinery components. Industrially, these sheets and plates are essential for manufacturing wear-resistant tools, dies, and components for chemical and petrochemical equipment. Their blend of durability, toughness, and corrosion resistance ensures they deliver long-lasting performance in even the most demanding industrial and structural applications.
