Wiraphan Sheets and Plates, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch Stainless Steel 348 Sheets and Plates tailored for industrial, structural, and high-temperature uses. With cutting-edge production facilities and a strong commitment to international quality standards, Wiraphan guarantees products that boast outstanding durability, corrosion resistance, and thermal stability. These Stainless Steel 348 Sheets and Plates are engineered to perform reliably even in high temperatures and moderately corrosive environments, making them perfect for applications in the chemical, petrochemical, power generation, and construction sectors. Thanks to their consistent quality, prompt delivery, and cost-effective solutions, Wiraphan has become a go-to partner for clients both locally and globally.
Stainless Steel 348 Sheets and Plates are a type of austenitic stainless steel, primarily made up of iron, 18–20% chromium, 8–12% nickel, and stabilized with niobium to prevent carbide precipitation. This unique composition offers remarkable resistance to intergranular corrosion, oxidation, and scaling at elevated temperatures. On the mechanical side, these sheets and plates provide high tensile strength, toughness, and thermal stability, along with good ductility and weldability. The niobium stabilization enhances durability during welding and ensures long-term performance in high-temperature settings, making 348 Sheets and Plates ideal for fabrication, forming, and structural applications in challenging industrial environments.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Mn | P | C | S | Cr | Si | Ni | Fe | Co |
| SS 348 | 2.0 | 0.045 | 0.080 | 0.030 | 19 | 1.0 | 11 | 66 | 0.2 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 348 | 1.4550 | S34800 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Stainless Steel 348 Sheets and Plates widely utilized in industries that demand high-temperature performance and corrosion resistance. In chemical and petrochemical facilities, they’re commonly used in piping systems, heat exchangers, and pressure vessels. In the power generation sector, they play a crucial role in boiler components, furnace parts, and turbine equipment. Additionally, in construction and industrial applications, these sheets and plates serve as structural supports, frameworks, and architectural elements that are exposed to heat and moderately corrosive conditions.
Stainless steel 348 sheets and plates are mainly used at high temperatures because they have excellent oxidation and corrosion resistance Commonly found in the air, aerospace, chemical and electrical industries, they are ideal for heat exchanger reactors and furnace side types. The addition of niobium increases weld resistance, making it the material of choice for welded structures at high temperatures Other applications include feedstocks, petrochemical plants and marine of the environment, making it stronger and more resistant to harsh conditions.
